 Post subject: SONY ICF-SW7600
PostPosted: Jul Thu 21, 2022 6:49 pm
Member
User avatar

Joined: Aug Thu 26, 2021 7:07 am
Posts: 447
Location: Ukraine
One man asked me to repair his not working SONY ICF-SW7600 which he bought in 2008 for parts.
I never have deal with SONY before so I immediately agreed.
It is legendary and well known model http://stephan.win31.de/sony76-2.htm
I also learned a lot from this thread viewtopic.php?f=4&t=303062&hilit=7600
So today I got it in my curved hands )
A little bit dirty enclosure but not bad at all
Attachment:
File comment: SONY ICF-SW7600
IMG_20220721_164310.jpg [ 611.94 KiB | Viewed 17528 times ]

It even turned on, but did not respond to the buttons.
Inside I was greeted by a stuffed cockroach
Attachment:
File comment: cockroach
IMG_20220721_173808.jpg [ 233.75 KiB | Viewed 17528 times ]

Traces of electrolyte from under the capacitors looked terrible, but the pads are surprisingly in good condition.
Attachment:
File comment: electrolyte
IMG_20220721_173828.jpg [ 339.84 KiB | Viewed 17528 times ]

Attachment:
File comment: pads
IMG_20220721_181253.jpg [ 277.45 KiB | Viewed 17528 times ]

So I ordered and am waiting for new capacitors.

_________________
i'm not sad i'm sober


Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Jul Thu 21, 2022 10:01 pm
Member
User avatar

Joined: Jan Tue 31, 2012 12:55 am
Posts: 22773
Location: Bryansford Village. Ireland.
I have dozens of SONY radios from all decades and I have never seen anything like this one.

My icf-7600D from 1985 is absolutely perfect in every respect, and a bit of a sleeper radio as it will receive strong FM signals with the antenna down and folded in place!
… and I'm in the Boonies
https://www.collinsdictionary.com/dicti ... of-nowhere


Attachments:
my sony icf-7600d.jpg
my sony icf-7600d.jpg [ 646.57 KiB | Viewed 17511 times ]
Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Jul Sun 24, 2022 7:58 am
Member
User avatar

Joined: Aug Thu 26, 2021 7:07 am
Posts: 447
Location: Ukraine
More photo
Attachment:
File comment: back
IMG_20220721_165056.jpg [ 203.45 KiB | Viewed 17444 times ]

Attachment:
File comment: inside
IMG_20220721_165051.jpg [ 376.74 KiB | Viewed 17444 times ]

Attachment:
File comment: antenna wires
IMG_20220721_165132.jpg [ 225.52 KiB | Viewed 17444 times ]

Attachment:
File comment: face cover
IMG_20220721_170324.jpg [ 253.51 KiB | Viewed 17444 times ]

Attachment:
File comment: dusty speaker
IMG_20220721_170314.jpg [ 258.83 KiB | Viewed 17444 times ]

Attachment:
File comment: LCD board
IMG_20220721_172329.jpg [ 241.21 KiB | Viewed 17444 times ]

Attachment:
File comment: inside
IMG_20220721_173219.jpg [ 286.03 KiB | Viewed 17444 times ]

Attachment:
File comment: LCD board back
IMG_20220721_173229.jpg [ 260.91 KiB | Viewed 17444 times ]

_________________
i'm not sad i'm sober


Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Jul Sun 24, 2022 8:10 am
Member
User avatar

Joined: Aug Thu 26, 2021 7:07 am
Posts: 447
Location: Ukraine
Attachment:
File comment: main board
IMG_20220721_173930.jpg [ 239.45 KiB | Viewed 17443 times ]

Attachment:
File comment: main board back
IMG_20220721_175006.jpg [ 321.62 KiB | Viewed 17443 times ]

It is not difficult to disassemble the receiver, so I changed more than two dozen capacitors. Quite a laborious job because you have to do the following operations:
1. twist the old cap.
2. cut off his legs.
3. rinse the place with alcohol.
4. dilute old solder with new solder.
5. use braid to remove all solder.
6. repeat step 3.
7. solder a new cap.
8. repeat step 3.
The mount is dense, so you have to act as carefully as possible so as not to damage neighboring parts.
Attachment:
File comment: old caps
IMG_20220723_133721.jpg [ 221.06 KiB | Viewed 17443 times ]

Attachment:
File comment: result
IMG_20220723_133729.jpg [ 285.25 KiB | Viewed 17443 times ]

I added 100nF cap above new C127 in the DC/DC converter
Attachment:
File comment: C127
IMG_20220723_113716.jpg [ 528.25 KiB | Viewed 17443 times ]

Attachment:
File comment: new C127
IMG_20220723_120655.jpg [ 271.69 KiB | Viewed 17443 times ]

_________________
i'm not sad i'm sober


Last edited by US7IGN on Jul Sun 24, 2022 9:03 am, edited 1 time in total.

Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Jul Sun 24, 2022 8:25 am
Member
User avatar

Joined: Aug Thu 26, 2021 7:07 am
Posts: 447
Location: Ukraine
The first power-up was successful, but I found that on AM the frequency did not match at 10kHz and the synthesizer needed to be tuned.
Attachment:
File comment: 5000
IMG_20220723_171310.jpg [ 428.66 KiB | Viewed 17442 times ]

Attachment:
File comment: 3kHz
3khz.jpg [ 243.74 KiB | Viewed 17442 times ]

Attachment:
File comment: 5kHz
5khz.jpg [ 245.66 KiB | Viewed 17442 times ]

On FM I could not receive a single station at all and decided that it also needed to be tuned.
Then I moved on to FM tuning and again, the values ​​were far from the desired ones. But it's easy to fix.
Attachment:
File comment: FM VCO
FM VCO.jpg
FM VCO.jpg [ 158.83 KiB | Viewed 17442 times ]

Attachment:
File comment: FM VCO
IMG_20220723_175333.jpg [ 278.63 KiB | Viewed 17442 times ]

_________________
i'm not sad i'm sober


Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Jul Sun 24, 2022 8:38 am
Member
User avatar

Joined: Aug Thu 26, 2021 7:07 am
Posts: 447
Location: Ukraine
And then I found that I could not adjust the FM input circuits and I had to set the oscillator signal level too high to hear anything. Checking the voltage on the transistor Q13 showed its absence.
Attachment:
File comment: FM
FM.jpg [ 100.13 KiB | Viewed 17441 times ]

I spent more than two hours to check all the elements and traces and find the reason for the lack of reception on the FM.
Under one of the capacitors glued to the board, corrosion apparently destroyed one of the tracks. I had a hard time finding the exact place where it happened. Next came radio microsurgery.
Attachment:
File comment: trace 1
IMG_20220723_215113.jpg [ 318.29 KiB | Viewed 17441 times ]

Attachment:
File comment: trace 2
IMG_20220723_215202.jpg [ 327.76 KiB | Viewed 17441 times ]

Attachment:
File comment: trace 3
IMG_20220723_220320.jpg [ 304.1 KiB | Viewed 17441 times ]

After that, I was able to adjust the FM and the radio perfectly receives both AM and FM.
After cleaning and assembling, I want to keep it for myself)
Attachment:
File comment: Final
IMG_20220723_184409.jpg [ 327.31 KiB | Viewed 17441 times ]

_________________
i'm not sad i'm sober


Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Jul Sun 24, 2022 12:25 pm
Member
User avatar

Joined: Aug Thu 26, 2021 7:07 am
Posts: 447
Location: Ukraine
video https://youtu.be/BPOSh1Z1fMM

_________________
i'm not sad i'm sober


Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Aug Mon 15, 2022 11:08 am
Member

Joined: Apr Wed 29, 2015 2:33 pm
Posts: 70
Location: Branson, Missouri
Boy, what an adventure! Great repair job on a classic portable. Thanks for all of the images and notes. Very informative!

Mike, N0TLD


Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Aug Mon 15, 2022 7:39 pm
Member
User avatar

Joined: Aug Thu 26, 2021 7:07 am
Posts: 447
Location: Ukraine
Thank you Mike!
I hope this will be useful to someone and perhaps inspire also to bring some old radio back to life.

_________________
i'm not sad i'm sober


Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Nov Sat 19, 2022 9:37 pm
Member
User avatar

Joined: Aug Thu 26, 2021 7:07 am
Posts: 447
Location: Ukraine
Today I started repairing another Sony ICF-SW7600.
Attachment:
File comment: Sony ICF-SW7600
IMG_20221119_151422.jpg [ 228.76 KiB | Viewed 16506 times ]

The owner complained about poor performance and lack of FM. When I opened it, I saw complete horror.
Attachment:
File comment: bad job
IMG_20221119_153003.jpg [ 288.98 KiB | Viewed 16506 times ]

After I threw out all the wrong parts and washed the board, I saw the consequences of the previous "repair".
Attachment:
File comment: soil
зображення_viber_2022-11-19_20-51-02-243.jpg [ 228.25 KiB | Viewed 16506 times ]

Attachment:
File comment: broken pads
зображення_viber_2022-11-19_20-44-48-843.jpg [ 745.59 KiB | Viewed 16506 times ]

Attachment:
File comment: broken pads
зображення_viber_2022-11-19_20-44-48-962.jpg [ 655.03 KiB | Viewed 16506 times ]

_________________
i'm not sad i'm sober


Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Nov Sun 20, 2022 12:58 am
Member

Joined: Aug Tue 31, 2021 4:50 pm
Posts: 173
Location: Vancouver, BC, Canada
Following with bated breath. Excellent photos.

Cheers Geoffqf


Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Nov Tue 22, 2022 5:18 pm
Member
User avatar

Joined: Mar Wed 11, 2015 12:46 am
Posts: 1809
Location: Boiling Springs, PA
Very useful info. I have the exact same receiver and have done the exact same repairs with the same damage to the board. Mine works fine now except AM is offset now and I need to use the fine tuning instead so I must have missed a defect. I don't plan to disassemble it again.

_________________
Jeff-W3JKO

My updated project and tutorial site:
https://ornerscorner.neocities.org/


Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Nov Tue 22, 2022 6:51 pm
Member
User avatar

Joined: Aug Thu 26, 2021 7:07 am
Posts: 447
Location: Ukraine
flyboy71 wrote:
Mine works fine now except AM is offset now and I need to use the fine tuning instead so I must have missed a defect.


Have you did alignment according to the service manual?

_________________
i'm not sad i'm sober


Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Nov Tue 22, 2022 8:01 pm
Member
User avatar

Joined: Mar Wed 11, 2015 12:46 am
Posts: 1809
Location: Boiling Springs, PA
No I didnt. Its not a big deal but maybe Ill open it up someday and run the alignment. When I did mine I didnt have all the info you provided which is very useful.

_________________
Jeff-W3JKO

My updated project and tutorial site:
https://ornerscorner.neocities.org/


Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Nov Sat 26, 2022 2:17 pm
Member
User avatar

Joined: Aug Thu 26, 2021 7:07 am
Posts: 447
Location: Ukraine
Since I only have electricity and internet for a few hours a day, mostly at night, doing repairs is much more difficult now. However, we continue.
First you need to restore the torn off C2 and C89 capacitors pads and PCB through hole rivet. It is B+ line
Attachment:
File comment: B+
B+.jpg [ 217.75 KiB | Viewed 16280 times ]

Attachment:
File comment: hole
IMG_20221125_023413.jpg [ 253.73 KiB | Viewed 16280 times ]

Attachment:
File comment: hole back
IMG_20221125_023420_1.jpg [ 354.08 KiB | Viewed 16280 times ]

Attachment:
File comment: new pad
IMG_20221125_025737.jpg [ 268.32 KiB | Viewed 16280 times ]

Attachment:
File comment: pad back
IMG_20221125_025743.jpg [ 357.28 KiB | Viewed 16280 times ]

Attachment:
File comment: C2
IMG_20221125_030453.jpg [ 253.54 KiB | Viewed 16280 times ]

Attachment:
File comment: C89 pad
IMG_20221125_035233.jpg [ 406.96 KiB | Viewed 16280 times ]

Attachment:
File comment: C89 new pad
IMG_20221125_035241.jpg [ 397.15 KiB | Viewed 16280 times ]

_________________
i'm not sad i'm sober


Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Nov Sat 26, 2022 2:26 pm
Member
User avatar

Joined: Aug Thu 26, 2021 7:07 am
Posts: 447
Location: Ukraine
C127 in the DC/DC converter mod is done.
Attachment:
File comment: C127 mod
IMG_20221125_033614.jpg [ 301.29 KiB | Viewed 16279 times ]

Attachment:
File comment: C127 imod 2
IMG_20221125_033625.jpg [ 259.88 KiB | Viewed 16279 times ]


All capacitors have been replaced.
Attachment:
File comment: all new caps
IMG_20221125_124445.jpg [ 272 KiB | Viewed 16279 times ]


The first power up is successful.
Attachment:
File comment: first power up
IMG_20221125_115238.jpg [ 332.66 KiB | Viewed 16279 times ]


2nd local adjustment
Attachment:
File comment: 2nd local adjustment
IMG_20221126_011041.jpg [ 288.33 KiB | Viewed 16279 times ]


3 kHz step adjustment
Attachment:
File comment: 3 kHz step adjustment
IMG_20221126_011152.jpg [ 255.32 KiB | Viewed 16279 times ]


5 kHz step adjustment
Attachment:
File comment: 5 kHz step adjustment
IMG_20221126_011250.jpg [ 255.95 KiB | Viewed 16279 times ]


FM VCO voltage adjustment
Attachment:
File comment: FM VCO voltage adjustment
IMG_20221126_014210.jpg [ 300.29 KiB | Viewed 16279 times ]

_________________
i'm not sad i'm sober


Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Nov Sat 26, 2022 2:32 pm
Member
User avatar

Joined: Aug Thu 26, 2021 7:07 am
Posts: 447
Location: Ukraine
Also, someone over-twisted the Fine Tuning RV1 pot and it was jammed. I had to disassemble it, clean it and reassemble it correctly.
Attachment:
File comment: RV1
RV1.jpg [ 40.24 KiB | Viewed 16279 times ]

Attachment:
File comment: RV1-1
RV1-1.jpg [ 62.53 KiB | Viewed 16279 times ]


The rest of the adjustment was also made and the plastic of the screen was polished.
Attachment:
File comment: fin
PXL_20221126_080425873.jpg [ 392.55 KiB | Viewed 16279 times ]

Attachment:
File comment: final
PXL_20221126_080544115.jpg [ 310.49 KiB | Viewed 16279 times ]

_________________
i'm not sad i'm sober


Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Nov Sun 27, 2022 3:29 am
Member
User avatar

Joined: Aug Thu 26, 2021 7:07 am
Posts: 447
Location: Ukraine
video https://youtu.be/9gQ3AwwvBBU

_________________
i'm not sad i'm sober


Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Jan Mon 30, 2023 10:01 pm
Member
User avatar

Joined: Aug Thu 26, 2021 7:07 am
Posts: 447
Location: Ukraine
I got another one 7600 in excellent condition for restoration. It is really new and has probably never been turned on. Complete with box, but hardly receives anything. The electrolytic capacitors need to be replaced and the adjustment must be checked.
Attachment:
File comment: 7600
IMG_20230130_135806.jpg [ 787.37 KiB | Viewed 15674 times ]

Attachment:
File comment: papers
IMG_20230130_135811.jpg [ 685.75 KiB | Viewed 15674 times ]

Attachment:
File comment: face
IMG_20230130_135836.jpg [ 792.29 KiB | Viewed 15674 times ]

Attachment:
File comment: back
IMG_20230130_140228.jpg [ 614.01 KiB | Viewed 15674 times ]

_________________
i'm not sad i'm sober


Top
 Profile

 Post subject: Re: SONY ICF-SW7600
PostPosted: Feb Wed 01, 2023 1:09 am
Member

Joined: Aug Tue 31, 2021 4:50 pm
Posts: 173
Location: Vancouver, BC, Canada
Spectacular!

And thanks for posting the pictures, they make great reference information!!!!

Geoff


Top
 Profile

Post New Topic Post Reply  [ 33 posts ]  Go to page 1, 2  Next

All times are UTC


Who is online

Users browsing this forum: No registered users and 7 guests



Search for:
Jump to:
Privacy Policy :: Powered by phpBB
